Models

	RevoBron 500W ERB500AWT Semi modular		RevoBron 600W ERB600AWT Semi modular		RevoBron 700W ERB700AWT Semi modular

Product Introduction

RevoBron is the successor of the well-known modular long-life series Triathlor. Durable quality components and a sophisticated technical design ensure stable and clean output voltages. RevoBron series has the international energy saving certificate 80 PLUS® Bronze and comes with two independent +12V rails to safely empower systems with high power consumption in 24/7 operation. The semi-modular cable management with the flexible and flat cables offers the best options for system installation or expansion.

RevoBron comes with a special accessory: COOLERGENIE is the intelligent 2-in-1 fan controller that enables semi-fanless and fan-delay function for external fans. The series perfectly suits performance gaming rigs, multimedia systems and home theatre PCs.

Efficiency & Power

80 PLUS® Bronze
84 to 91 percent efficiency at 230V and 10 to 100 percent load. 80 PLUS® Bronze certified.
ErP Lot 6 2013 and 2014 ErP Lot 3 ready!
Helps systems to meet the EU eco-design directive ErP Lot 6 2013 (< 0.5W in standby mode*) & 2014 ErP Lot 3 due to an improved, high-efficient 5V standby (+5Vsb) circuitry.
* only in combination with an ErP Lot 6 2013 ready mainboard
DC-to-DC Design
The secondary voltages (+5V and +3.3V) are generated by the primary voltage rail (+12V). Positive effect: Higher efficiency, clean output voltages (low ripple & noise) and a perfect voltage regulation at all loads.
Full GPU & CPU Power
99 percent of the PSU power can be delivered by two stable 12V rails to safely empower high-performance processors and graphics cards.

Connectivity & Compatibility

Modular & Flat Cables
Simplify the cable routing and enhance the airflow inside the case.
Intel® Kaby Lake™ Ready!
Full support of the C6/C7 energy-saving functions of Intel® processors, first introduced with the Haswell™ generation.
Intel ATX 12V v2.4
Compliant with the Intel Power Supply Design Guide for Desktop Platform Form Factors Revision 1.31 April 2013.
Worldwide Compatibility
100-240V AC input with automatic adjustment and up to 99% active Power Factor Correction (PFC) for global usage.

Cooling

COOLERGENIE
The semi-fanless fan control for external fans offers the possibility to connect up to three fans. Depending on the load of the CPU fan, the case fans start to spin. Coolergenie also provides fans with the fan delay function. This function keeps the connected fans running for up to 60 seconds after the PC shutdown to dissipate the remaining heat and extending the life of your hardware.
Efficient Cooling
Durable 12cm-Twister Bearing™ fan with Batwing fan blades for optimal cooling, low noise generation and longer lifetime (>160,00h MTBF).
SpeedGuard
Silent and powerful cooling performance due to the advanced and intelligent fan speed control.

Quality & Safety

100% 105°C Japanese Electrolytic Capacitors
Highest component standards for maximum stability and durability.
Non-Stop 24/7 @ 40°C
Non-stop industrial class performance at 40°C/104°F ambient.
SafeGuard
Multiple protection circuitry of OCP, OVP, UVP, OPP, SCP and SIP.

Dimensions & Warranty

Compact Housing with Powder Coating
Dimensions (W x H x D): 150 mm x 86 mm x 140 mm
Warranty
3 years vendor warranty

Included in the delivery

RevoBron 500W, 600W or 700W power supply
AC cord
Flat modular cables
Bag for modular cables
4 screws
Cable Ties
COOLERGENIE fan control
User manual

Information for Dealers

Model	ERB500AWT	ERB600AWT	ERB700AWT
Power Supply Dimensions (D x W x H)	140 x 150 x 86 mm	140 x 150 x 86 mm	140 x 150 x 86 mm
Power Supply Surface	Powder Coating	Powder Coating	Powder Coating
Power Supply Weight	1.6 kg	1.6 kg	1.6 kg
Product Box - Dimensions	231 x 217 x 98.5 mm	231 x 217 x 98.5 mm	231 x 217 x 98.5 mm
Product Box - Gross Weight	2.2 kg	2.3 kg	2.4 kg
Master Carton - Dimensions	467 x 259 x 352 mm	467 x 259 x 352 mm	467 x 259 x 352 mm
Master Carton - Gross Weight	13.6 kg	15.0 kg	15.2 kg
Pieces / Master Carton	6	6	6
EAN-Code	4713157722966	4713157722973	4713157722980

For Russian market please note: Не для бытового применения.

Cables and Connectors

	ERB500 AWT	ERB600 AWT	ERB700 AWT
Mainboard 24 Pin	1x 60cm	1x 60cm	1x 60cm
CPU 4+4 Pin	1x 70cm	1x 70cm	1x 70cm
6+2 Pin (8 Pin) PCI-E	1x 50/15cm (2xPCI-E)	2x 50/15cm (4xPCI-E)	2x 50/15cm (4xPCI-E)
SATA	2x 450/15/15cm (6xSATA)	2x 450/15/15/15cm (8xSATA)	2x 450/15/15/15cm (8xSATA)
4P Molex	1x 450/15/15/15cm (4xMolex)	1x 450/15/15/15cm (4xMolex)	1x 450/15/15/15cm (4xMolex)
FDD (apaptor)	1x 10cm	1x 10cm	1x 10cm

Enermax Coolergenie

Enermax Coolergenie is a semi-fanless fan controller with fan delay function after shutdown. Extend your CPU fan PWM signal to 3 external fans (max. 2A) or use the semi-fanless modes to shut down all connected fans in idle. You can set the fans to start on 40% (Whisper Mode) or 55% (Silence Mode) system load. No matter which setup you choose, after shutdown the fans keep spinning for approximately 60 seconds to allow accumulated heat to exit the case and prevent long term damage to your hardware.

Specifications

Model / DC Output	+3.3V	+5V	+12V1	+12V2	-12V	5Vsb	Peak Power	Total Power
ERB500AWT	22A	18A	25A	25A	0.3A	2.5A	550W*	500W
	110W		498W (41.5A)		3.6W	12.5W
ERB600AWT	22A	18A	30A	30A	0.3A	2.5A	660W*	600W
	120W		600W (50A)		3.6W	12.5W
ERB700AWT	22A	18A	35A	35A	0.3A	2.5A	770W*	700W
	130W		696W (58A)		3.6W	12.5W

* Peak power may last up to 60 seconds.

Efficiency & Noise Level

The RevoBron series complies with the requirements of the EU regulation for computer systems No. 617/2013 (valid from 1st of July 2014).

	10% load @ 230V		20% load @ 230V		50% load @ 230V		100% load @ 230V
	Eff.	dB(A)	Eff.	dB(A)	Eff.	dB(A)	Eff.	PF	dB(A)
ERB500AWT	84%	15.2	88%	15.2	89%	15.2	85%	0.99	18.4
ERB600AWT	85%	15.2	89%	15.2	90%	15.2	86%	0.99	22.4
ERB700AWT	87%	15.4	90%	15.4	91%	15.4	86%	0.99	24.8
