Models

ENP350AGT | 350W | non-modular
ENP450AGT | 450W | non-modular
ENP500AGT | 500W | non-modular
ENP550AWT | 550W | non-modular*

* This model is end of life (EOL). It is possible that single units are still available on the market.
Alternatively, we suggest you to buy NAXN 500W or NAXN 82+ 450/550/650W

Information

ErP Lot 6 ready!
Help systems to meet EU eco-design directive ErP/EuP Lot 6 (<1W in standby mode) due to improved, high-efficient 5V standby (+5Vsb) circuitry.
Intel® Haswell™ ready!
Supports the C6/C7 energy-saving functions of the latest Intel® CPUs incl. the forthcoming Intel® Haswell™ generation.
Intel ATX 12V v2.3
Compliant with the latest desktop power supply design guide. Full support of most current CPU: Intel® Core 2 Duo™/ Quad™/ Extreme™ / i7™ / i5™ / i3™ and AMD® Athlon™ 64X2/X4 or Phenom™ X3/X4.
Multi-Rail Design
Stable and reliable power supply with two 12V rails.
AirGuard
Patented air-intake with optimal aero-dynamical design reduces noisy air turbulences.
Silent Cooling
Ultra quiet fan with intelligent RPM control guarantees cool performance and silent operation.
SafeGuard
Multiple protection circuitry of OVP, UVP, SCP, OPP and SIP.
Active PFC
Excellent active Power Factor Correction (PFC) with up to 0.99 to minimize power waste.
Worldwide Compatibility
100-240V AC input with automatic adjustment for global usage (only ENP550AWT).
Dimensions (W x H x D)
150 x 86 x 140mm.
Warranty
3 years vendor warranty.

Specifications

Model / DC Output	+3.3V	+5V	+12V1	+12V2	-12V	5Vsb	Peak Power	Total Power
ENP350AGT	21A	17A	15A	15A	0.3A	2.5A	385W	350W
	110W		300W (25A)		3.6W	12.5W
ENP450AGT	22A	18A	21A	18A	0.3A	2.5A	495W	450W
	120W		360W (30A)		3.6W	12.5W
ENP500AGT	22A	19A	24A	21A	0.3A	2.5A	550W	500W
	120W		408W (34A)		3.6W	12.5W
ENP550AWT	25A	25A	19A	19A	0.8A	3A	605W	550W
	130W		456W (38A)		9.6W	15W

Cables & Connectors

	ENP350AGT	ENP450AGT	ENP500AGT	ENP550AWT
ATX12V 20+4 Pin	1x (50cm)	1x (50cm)	1x (50cm)	1x (50cm)
CPU 4+4 Pin	1x (60cm)	1x (60cm)	1x (60cm)	1x (60cm)
PCI-E 6 Pin	1x (50cm)	1x (50cm)	1x (50cm)	1x (50cm)
PCI-E 6+2 (8)Pin	-	1x (50cm)	1x (50cm)	1x (50cm)
SATA	4x	5x	5x	5x
4P Molex	4x	4x	4x	4x
FDD	1x	1x	1x	1x

Models

ENP450AWT-B | 450W | non-modular, 80 PLUS® Bronze
ENP550AWT-B | 550W | non-modular, 80 PLUS® Bronze
ENP650AWT-B | 650W | non-modular, 80 PLUS® Bronze*
ENM750AWT | 750W | modular, 80 PLUS® Bronze
ENM850EWT | 850W | modular, 80 PLUS® Bronze

* This model is end of life (EOL). It is possible that single units are still available on the market.

Information

80 PLUS® Bronze efficiency
Up to 88% efficiency at 230V and 20-100% load. 80 PLUS® Bronze certified.
Future ready and flexible*
All-round modular cable management. 10/12P sockets for possible connector changes of upcoming high-performance CPU and graphics card generations.
* only ENM750AWT & ENM850EWT
Full graphics power
Supports SLI™ systems (except ENP450AWT-B) and CrossFireX™ systems.
ENERGY STAR 5.0 ready!
Support computer system to meet ENERGY STAR 5.0 standard.
Intel® Haswell™ ready!
Supports the C6/C7 energy-saving functions of the latest Intel® CPUs incl. the forthcoming Intel® Haswell™ generation.
ErP Lot 6 ready!
Help systems to meet EU eco-design directive ErP/EuP Lot 6 (<1W in standby mode) due to improved, high-efficient 5V standby (+5Vsb) circuitry (except ENM750AWT and ENM850EWT).
Intel ATX 12V v2.3
Compliant with the latest desktop power supply design guide. Full support of most current CPU: Intel® Core 2 Duo™/ Quad™/ Extreme™ / i7™ / i5™ / i3™ and AMD® Athlon™ 64X2/X4 or Phenom™ X3/X4.
Multi-Rail Design
Stable and reliable power supply with up to four powerful 12V rails.
AirGuard
Patented air-intake with optimal aero-dynamical design reduces noisy air turbulences.
Silent Cooling
Ultra quiet fan with intelligent RPM control guarantees cool performance and silent operation.
HeatGuard
Keeping PSU fan running for 30-60 seconds after shut down to dissipate the remaining system heat and prolonging system lifetime.
Non-Stop @ 40°C
Non-stop industrial class performance at 40°C/104°F ambient.
SafeGuard
Multiple protection circuitry of OVP, UVP, SCP, OPP and SIP.
Active PFC
Excellent active Power Factor Correction (PFC) with up to 0.99 to minimize power waste.
Worldwide Compatibility
100-240V AC input with automatic adjustment for global usage.
Dimensions (W x H x D)
150 x 86 x 140mm (ENM750AWT/ENM850EWT: 150 x 86 x 160mm).
Warranty
3 years vendor warranty.

Specifications

Model / DC Output	+3.3V	+5V	+12V1	+12V2	+12V3	+12V4	-12V	5Vsb	Peak Power	Total Power
ENP450AWT-B	25A	20A	17A	17A	-	-	0.8A	3A	495W	450W
ENP450AWT-B	120W		360W (30A)				9.6W	15W	495W	450W
ENP550AWT-B	25A	25A	19A	19A	-	-	0.8A	3A	605W	550W
ENP550AWT-B	130W		456W (38A)				9.6W	15W	605W	550W
ENP650AWT-B	25A	25A	25A	25A	-	-	0.8A	3A	715W	650W
ENP650AWT-B	150W		540W (45A)				9.6W	15W	715W	650W
ENM750AWT	22A	22A	35A	35A	-	-	0.3A	3A	825W	750W
ENM750AWT	130W		648W (54A)				3.6W	15W	825W	750W
ENM850EWT	28A	30A	20A	20A	30A	30A	0.8A	3A	935W	850W
ENM850EWT	180W		750W (62.5A)				9.6W	15W	935W	850W

Cables & Connectors

	ENP450AWT-B	ENP550AWT-B	ENP650AWT-B	ENM750AWT	ENM850EWT
ATX12V 20+4 Pin	1x	1x	1x	1x (55cm)	1x (55cm)
CPU 4+4 Pin	1x	1x	1x	1x (60cm)	1x (60cm)
CPU 8 Pin	-	-	-	1x (60cm)	1x (60cm)
PCI-E 6+2 (8)Pin	1x	1x	2x	2x (50cm)	2x (50cm)
PCI-E 6+2 (8)Pin (modular)	-	-	-	2x (50cm)	4x (50cm)
PCI-E 6 Pin	1x	1x	-	-	-
SATA	5x	5x	7x	10x modular	10x modular
4P Molex	4x	4x	4x	5x modular	5x modular
FDD	1x	1x	1x	1x modular	1x modular
