ENERMAX.CO.UK - MaxTytan

Models

MaxTytan 750W
EMT750EWT
Fully modular

MaxTytan 800W
EMT800EWT
Fully modular

>> More products with DFR™-Technology

Product Introduction

MaxTytan is the flagship PSU series of Enermax. High end components and years of experience in power supply technology allow Enermax to create a product with the highest standards of efficiency and reliability. With over 94% of efficiency, the MaxTytan series is certified 80PLUS® Titanium. All models have a semi-fanless function and a 139mm Twister Bearing fan, granting an extremely quiet operation. The fully-modular PSU comes with individually sleeved cables (SLEEMAX™) offering further protection and the highest flexibility for system installation. This high-end PSU is designed for professional systems requiring the highest standards in quality and performance.

Efficency

80 PLUS® Titanium
Over 94% efficiency at 230VAC between 20 and 100% load. The MaxTytan series is 80 PLUS® Titanium certified.
Support of EU Eco-Design Regulations
MaxTytan helps systems to meet the EU eco-design directive ErP Lot 6 2013 and ErP Lot 3 2014 (< 0.5W in standby mode*) due to a high-efficient 5V standby (+5Vsb) circuitry as well as the EU regulation no. 617/2013 demanding amongst others 85% efficiency at 50% load and 82% at 20% and 100% load.
* only in combination with an ErP Lot 6 2014 ready mainboard

Power

DC-to-DC Design
The secondary voltages (+5V and +3.3V) are generated by the primary voltage rail (+12V). Positive effect: Higher efficiency, clean output voltages (low ripple & noise) and a perfect voltage regulation at all loads.
Full Gaming Power
Six 6+2P (8P) PCI-E connectors to power high-end graphics cards and multi-GPU systems (MGPU & SLI™).
Full GPU & CPU Power
Massive 12V rail to power high-performance and overclocked processors and graphics cards.

Connectivity

SLEEMAX™ Cables
Individually sleeved cables for comfortable cable management and higher safety.
Full-modular Cable Management
Cables can be completely removed in order to make the system installation and cable routing more comfortable and to improve the air circulation inside the case.
DXXII ready!
Full support to high end graphics cards thanks to six 6+2P (8P) PCI-E connectors.

Cooling

Semi-Fanless Operation
Thanks to the smart semi-fanless control MaxTytan series operates completely silent up to 55% of system load.
Air Cooling by Enermax
The integrated 13.9cm fan with patented Twister Bearing™ technology ensures an efficient and continuously silent cooling and long lifetime.

Dust Free Rotation™ Technology

DFR™ (Dust Free Rotation) technology
The patented technology DFR ™ allows the fan to remove automatically the dust from the fan blades.
After starting the PSU, the fan spins in reverse at full speed removing all the dust.
After that it will shift back to the normal operation mode.
D.F. Switch
Allows to manually activate the DFR™ mode of the fan within operation.

Compatibility

Intel® ATX12V v2.4
Compliant with the Intel Power Supply Design Guide for Desktop Platform Form Factors Revision 1.31 April 2013.
Intel® Kaby Lake™ Ready!
Full support of the C6/C7 energy-saving functions of Intel® processors, first introduced with the Haswell™ generation.
DXXII ready!
Full support of recent DX12 graphics cards thanks to minimum six 6+2P (8P) PCI-E connectors.
Worldwide Compatibility
Automatic 100-240V AC input for global usage and up to 99% active Power Factor Correction (PFC).

Quality & Safety

Durable & High-Quality Components
Enermax only uses high-quality components including first-class Japanese 105°C electrolytic capacitors for maximum stability and durability.
SafeGuard
The multiple protection circuit keeps the power supply and the system save from damage in case of short circuit (SCP), over voltage (OVP), under voltage (UVP), over current (OCP), over temperature (OTP), over power (OPP) as well as surges and inrush current (SIP).
24/7 @ 50°C
Non-Stop industrial class performance at 50°C ambient temperature.

Warranty

10 Years Manufacturer Warranty

Dimensions

Dimensions (W x H x D)
EMT750EWT: 150mm x 86mm x 180mm
EMT800EWT: 150mm x 86mm x 180mm

Acessory

Power Supply MaxTytan 750W | 800W
Modular Cables
Cable bag
4 screws
6 Cable Ties
Cord Organizer Set
User manual

Information for Dealers

Model	EMT750EWT	EMT800EWT
Power Supply Dimensions (D x W x H)	180 x 150 x 86 mm	180 x 150 x 86 mm
Power Supply Weight	3.2 kg	3.2 kg
Product Box - Dimensions	351(D) x 264(W) x 159(H) mm	351(D) x 264(W) x 159(H) mm
Product Box - Gross Weight	4.5 kg	4.5 kg
Master Carton - Dimensions	505(D) x 380(W) x 295(H)mm	505(D) x 380(W) x 295(H)mm
Master Carton - Gross Weight	15 kg	15 kg
Pieces / Master Carton	3	3
EAN-Code	4713157722744	4713157722737

For Russian market please note: Не для бытового применения.

Models

MaxTytan 1050W
EDT1050EWT
Fully modular

MaxTytan 1250W
EDT1250EWT
Fully modular

>> More products with DFR™-Technology

Product Introduction

Efficiency

80 PLUS® Titanium
Over 94% efficiency at 230VAC between 20 and 100% load. The MaxTytan series is 80 PLUS® Titanium certified.
Support of EU Eco-Design Regulations
MaxTytan helps systems to meet the EU eco-design directive ErP Lot 6 2013 and ErP Lot 3 2014 (< 0.5W in standby mode*) due to a high-efficient 5V standby (+5Vsb) circuitry as well as the EU regulation no. 617/2013 demanding amongst others 85% efficiency at 50% load and 82% at 20% and 100% load.
* only in combination with an ErP Lot 6 2014 ready mainboard

Power

DC-to-DC Design
The secondary voltages (+5V and +3.3V) are generated by the primary voltage rail (+12V). Positive effect: Higher efficiency, clean output voltages (low ripple & noise) and a perfect voltage regulation at all loads.
Full Gaming Power
Eight 6+2P (8P) PCI-E connectors to power high-end graphics cards and multi-GPU systems (MGPU & SLI™).
Full GPU & CPU Power
Massive 12V rail to power high-performance and overclocked processors and graphics cards.

Connectivity

SLEEMAX™ Cables
Individually sleeved cables for comfortable cable management and higher safety.
Full-modular Cable Management
Cables can be completely removed in order to make the system installation and cable routing more comfortable and to improve the air circulation inside the case.
DXXII ready!
Full support to high end graphics cards thanks to eight 6+2P (8P) PCI-E connectors.

Know Your Power Consumption!

Wattage Meter
MaxTytan 1050W and 1250W come with a digital wattage meter for a fast read-out of your power consumption.

Cooling

Semi-Fanless Operation
Thanks to the smart semi-fanless control MaxTytan series operates completely silent up to 70%* of system load.
*EMT1250EWT = 60%
Coolergenie
The semi-fanless fan control for external fans offers the possibility to connect up to three fans. Depending on the load of the CPU fan, the case fans start to spin. Coolergenie also provides fans with the fan delay function. This function exhausts warm air out of the system for up to 60 seconds after the system is shut down.
Air Cooling by Enermax
The integrated 13.9cm fan with patented Twister Bearing™ technology ensures an efficient and continuously silent cooling and long lifetime.

Dust Free Rotation™

DFR™ (Dust Free Rotation) technology
The patented technology DFR ™ allows the fan to remove automatically the dust from the fan blades.
After starting the PSU, the fan spins in reverse at full speed removing all the dust.
After that it will shift back to the normal operation mode.

Compatibility

Intel® ATX12V v2.4
Compliant with the Intel Power Supply Design Guide for Desktop Platform Form Factors Revision 1.31 April 2013.
Intel® Kaby Lake™ Ready!
Full support of the C6/C7 energy-saving functions of Intel® processors, first introduced with the Haswell™ generation.
DXXII ready!
Full support of recent DX12 graphics cards thanks to eight 6+2P (8P) PCI-E connectors.
Worldwide Compatibility
Automatic 100-240V AC input for global usage and up to 99% active Power Factor Correction (PFC).

Quality & Safety

Durable & High-Quality Components
Enermax only uses high-quality components including first-class Japanese 105°C electrolytic capacitors for maximum stability and durability.
SafeGuard
The multiple protection circuit keeps the power supply and the system save from damage in case of short circuit (SCP), over voltage (OVP), under voltage (UVP), over current (OCP), over temperature (OTP), over power (OPP) as well as surges and inrush current (SIP).
24/7 @ 50°C
Non-Stop industrial class performance at 50°C ambient temperature.

10 Years Manufacturer Warranty

Abmessungen

Dimensions (W x H x D)
EDT1050EWT: 150mm x 86mm x 200mm
EDT1250EWT: 150mm x 86mm x 200mm

Acessory

Power Supply MaxTytan 1050W | 1250W
Modular Cables
Cable bag
4 screws
6 Cable Ties
Cord Organizer Set
COOLERGENIE fan control
User manual

Information for Dealers

Model	EDT1050EWT	EDT1250EWT
Power Supply Dimensions (D x W x H)	200 x 150 x 86 mm	200 x 150 x 86 mm
Power Supply Weight	3.7 kg	3.7 kg
Product Box - Dimensions	351(D) x 263(W) x 158(H) mm	351(D) x 263(W) x 158(H) mm
Product Box - Gross Weight	5.2 kg	5.2 kg
Master Carton - Dimensions	505(D) x 380(W) x 295(H)mm	505(D) x 380(W) x 295(H)mm
Master Carton - Gross Weight	16.75 kg	16.75 kg
Pieces / Master Carton	3	3
EAN-Code	4713157722713	4713157722645

For Russian market please note: Не для бытового применения.

Specifications

Model / DC Output	+3.3V	+5V	+12V1	-12V	5Vsb	Peak Power	Total Power
EMT750EWT	20A	20A	62.5A	0.3A	3A	825W*	750W
EMT750EWT	100W		750W	3.6W	15W	825W*	750W
EMT800EWT	20A	20A	66.5A	0.3A	3A	880W*	800W
EMT800EWT	100W		798W	3.6W	15W	880W*	800W
EMT1050EWT	20A	20A	87.5A	0.3A	3A	1155W*	1050W
EMT1050EWT	100W		1050W	3.6W	15W	1155W*	1050W
EMT1250EWT	20A	20A	104A	0.3A	3A	1375W*	1250W
EMT1250EWT	100W		1248W	3.6W	15W	1375W*	1250W

*Peak power may last up to 60 seconds.

Efficiency & Noise Level

The MaxTytan series complies with the requirements of the EU regulation for computer systems No. 617/2013 (valid from 1st of July 2014).

	10% load @ 230V		20% load @ 230V		50% load @ 230V		100% load @ 230V
	Eff.	dB(A)	Eff.	dB(A)	Eff.	dB(A)	Eff.	PF	dB(A)
EMT750EWT	90.33%	0	93.68%	0	95.16%	0	93.48%	0.98	17.1
EMT800EWT	91.1%	0	94.2%	0	95.1%	0	93.1%	0.98	17.1
EDT1050EWT	tba	0	tba	0	tba	0	tba	tba	tba
EDT1250EWT	tba	0	tba	0	tba	0	tba	tba	tba

* Eff. = Efficiency | PF = Power Factor

Cables and Connectors

	EMT750EWT	EMT800EWT
Mainboard 28 Pin	1x 60cm	1x 60cm
CPU 4+4 Pin	1x 60cm	1x 60cm
CPU 8 Pin	1x 60cm	1x 60cm
6+2 Pin (8 Pin) PCI-E	6x 60cm	6x 60cm
SATA	12x 3x50 / 3x65 / 3x80 / 3x95cm	12x 3x50 / 3x65 / 3x80 / 3x95cm
4P Molex	4x 1x50 / 1x65 / 1x80 / 1x95cm	4x 1x50 / 1x65 / 1x80 / 1x95cm
FDD	1x 10cm	1x 10cm

	EDT1050EWT	EDT1250EWT
Mainboard 28 Pin	1x 60cm	1x 60cm
CPU 4+4 Pin	1x 60cm	1x 60cm
CPU 8 Pin	1x 60cm	1x 60cm
6+2 Pin (8 Pin) PCI-E	8x 60cm	8x 60cm
SATA	16x 4x50 / 4x65 / 4x80 / 4x95cm	16x 4x50 / 4x65 / 4x80 / 4x95cm
4P Molex	8x 2x50 / 2x65 / 2x80 / 2x95cm	8x 2x50 / 2x65 / 2x80 / 2x95cm
FDD	1x 10cm	1x 10cm
